Design for manufacturing (DFM) is a process that entails designing components, parts, or products to optimize the manufacturing process used to produce them. Ultimately, DFM helps maximize the efficiency and cost-effectiveness of manufacturing processes through optimized product designs that address any potential discrepancies or mistakes. People may also refer to DFM as design for manufacturing and assembly (DFMA).
The Design for Manufacturing Process
(Click to Expand) There are five main principles behind the DFM process that help optimize designs to prepare them for manufacturing. These principles are as follows:
1. Process
The first step of the DFM process is to select the appropriate manufacturing process for the component or product. For example, thermoforming may be a better process for low-volume parts compared to less efficient injection molding processes.
2. Design
The next aspect of the DFM process is the design, which involves drawing the product or part based on the principles specific to the selected manufacturing process.
3. Material
After the drawings are completed, it’s time to select the right materials for the design. Certain contributing factors to material selection may include mechanical, thermal, optical, electrical, and fire-retardant properties, along with color.
4. Environment
Parts or products must be designed to hold up in the environments in which they’ll be used. Otherwise, they won’t be able to function properly, regardless of the quality of the design.
5. Compliance/Testing
Products and components are required to maintain compliance with quality and safety standards. These standards could include industry standards along with company or third-party standards. It’s also important for manufacturers to have ISO certification.
Advantages of Design for Manufacturing
There are several key benefits of using DFM processes to design products before manufacturing. These include:
Faster time-to-market
Reduced production costs for parts and products
Parts can be combined to reduce assembly steps and part quantities
Quicker product development
The ability to identify and eliminate faults or mistakes
Safer workspaces resulting from removal and relocation of construction activities
Less time needed to bring production up to speed
Considerations for Design for Manufacturing
There are several key factors to consider for the DFM process. These considerations include:
Standardization of Parts and Materials. Standardized materials and parts can reduce the amount of time it takes to initiate production due to their consistency and availability.
Minimized Part Count. The fastest way to lower production costs is to minimize the number of parts used, which subsequently reduces the amount of material used in manufacturing.
Efficient Joining. It’s best to find ways to join parts together without the need for fasteners or adhesives of any kind. If they are required, try to figure out how to minimize the amount needed and use standard fasteners as much as possible.
Minimized Reorientation of Components. Designs should ensure that a minimal amount of manual interaction is required for part or product manufacturing.
Modular Assembly Creation. Using non-customized product modules can allow for changes to products without any loss of functionality.
Simplification of Manufacturing. It’s important to minimize the number of manufacturing processes and operations to prevent them from becoming too complex.
Appropriate Surface Finishes. Aesthetics may be important to a finished product, but it’s more important to choose a surface finish that allows for optimal functionality.
Get the Design and Build Services You Need with Chapter 2
Through effective DFM, you can make sure the manufacturing process for various parts and products is consistently efficient and profitable. With the help of Chapter 2 as your contract manufacturer, you can ensure manufacturing processes meet your project’s specific demands. For additional information about our services, contact us today. You can also request a quote for our services to get started on your next project.
Welding is the process of joining two surfaces together by applying heat, pressure, or a combination of both. The types of welds used to create the weld joint can be categorized into various types, which are largely defined by their cross-sectional shape and the methods used to produce them. Understanding the various weld types and their distinct characteristics and advantages is the first step toward achieving a reliable, high-quality weld that meets your application-specific requirements.
Here, we cover some of the most common weld types, their key benefits, and the applications for which they are best suited. To learn more about Chapter 2’s welding capabilities, visit our capabilities page.
Fillet Welds
A fillet weld joins two surfaces perpendicularly, forming an approximate right angle between them. This style of weld can be further categorized into the following subtypes:
Full fillet weld. With full fillet welds, the weld size is equal to the thickness of the thinner part being joined.
Staggered intermittent fillet weld. Staggered intermittent fillet welds are characterized by the formation of two lines of offset intermittent welding on both sides of the joint.
Chain intermittent fillet weld. Chain intermittent fillet welds involve the formation of two lines of intermittent fillet welds that are approximately opposite to one another on either side of a T joint.
The versatility and low cost of fillet welds have made them one of the most widely-used joints in the welding industry. Typical applications include:
Connecting flanges to pipes
Bracing connections
Shear tabs
Cover plates
Column bases
Seam and stitch welds
Groove Welds
Groove welds allow parts to be joined in the same plane by depositing welding beads in a groove between them. The basic types of groove welds include:
Flare-bevel weld
Flare-V weld
Single-bevel groove weld
Single-J groove weld
Single-U groove weld
Single-V groove weld
Square groove weld
Compared with other forms of welding, the groove welding process is generally more time-consuming, harder to perform, and typically requires special beveling on one or both surfaces being joined. However, it creates an easy-to-inspect, high-strength weld and offers good distortion control. Common applications of groove welds include:
Moment connections
Column splices
Hollow structural steel (HSS) connections
Surfacing Weld
Surfacing is a welding process in which the weld is applied to the surface rather than the joint to achieve certain properties or dimensions. This is accomplished by depositing one or more strings of weave beads onto an unbroken surface. The most common types of surfacing welds include:
Flux-cored arc welding (FCAW) surfacing
Furnace fusing
Gas metal arc welding (GMAW) surfacing
Gas tungsten arc welding (GTAW) surfacing
Oxy-acetylene surface welding
Plasma arc surfacing
Submerged arc welding (SAW) surfacing
Submerged metal arc welding (SMAW) surfacing
Surfacing welds are commonly used to add a wear-resistant layer of metal to an object to strengthen its surface or rebuild worn areas. In these cases, a metal with a greater wear resistance than the base metal is used to perform the welding. This technique is one of the most cost-effective methods for protecting and prolonging the life of equipment and tools used in aggressive, high-wear applications. Surface welding can also be used in conjunction with square butt joints to enhance the quality of the final weld.
Plug Weld
Plug welds are circular welds used to fasten two surfaces together through a small hole in one of the surfaces. In automotive applications, plug welds are commonly used in place of spot welds when there is insufficient space to accommodate spot welding equipment. The resulting weld is often stronger than a spot weld. Similarly, plug welds can be used to refill damaged holes in expensive aerospace components, returning them to a like-new state and saving companies on MRO costs.
Other applications include:
Welding rods inside a pipe
Joining metals that differ in thickness
Auto body manufacturing and repair
Slot Weld
With slot welds, one surface is joined to another through an elongated hole. The difference between plug and slot welds is that the plug weld’s shape is characterized by its diameter, whereas the slot weld’s shape is characterized by both diameter and length. Depending on the part’s specifications, one end of the hole may be open, or the hole can be partially or completely filled with weld material.
Slot welds are beneficial when the part’s design requires an overlapping between two surfaces. Specific uses of slot welds include:
Transmitting shear force in lap joints
Preventing buckling in overlapped parts
Flash Weld
Flash welding is a method of resistance welding that eliminates the need for filler metals. During the flash welding process, a current is applied to create a resistance between the two surfaces to be joined. When the two surfaces come together at small contact points, the current flows and melts the material.
The melted material then exits the joint in a spray of molten particles, which creates the distinctive flashing action. Oxides and other contaminants are eliminated from the interface while a heat-softened zone is formed at the ends of the two surfaces. When enough material has melted, a force is then applied to join the surfaces. This facilitates the creation of a butt weld with no residual melted material in the joint.
The flash welding process is fast, economical, and capable of fusing dissimilar metals with different melting points. Flash welds are often used for:
Joining sections of mainline rail in railway construction
Connecting thick workpieces such as chains or pipes
Merging metal sheets, rods, and bars
Seam Weld
Seam welds allow materials to be overlapped and joined along a continuous seam. This type of weld can be created using two methods:
Resistance seam welding. Resistance seam welding is an adaptation of spot welding that uses motor-driven wheels instead of stationary rods for the welding electrodes. Common uses include sheet metal fabrication and the manufacturing of automotive components such as fuel tanks, radiators, and steel drums.
Friction seam welding. With friction seam welding, heat is generated using friction instead of electrodes. This allows the surfaces to be merged while in the solid phase, thereby eliminating the occurrence of interdiffusion. Friction seam welding is often preferred for materials that are inherently difficult to weld using traditional arc welding methods.
Benefits of seam welding include:
Provides sturdy, durable welds
Relatively easy to perform
Ideal for manufacturing liquid- and gas-tight vessels
Spot Weld
Spot welding is a form of resistance welding used to merge two or more pieces of sheet metal without the use of filler material. This is achieved by concentrating an electrical current into small, precisely-spaced spots between the adjoined surfaces. Shaped copper alloy electrodes are used to convey the electrical current through the sheet metal pieces at the predetermined locations. Once the material is melted, the current is removed and pressure is maintained while the molten material hardens to create the spot weld.
Spot welds are relatively easy and inexpensive to create, making them a popular weld choice in several key industries, including:
Automotive
Aerospace
Construction
Electronics
Metal furniture building
Railway
Upset Weld
Upset welding is a form of resistance welding that produces fusion concurrently across an area of adjoining surfaces, or progressively along a joint, using a combination of heat and pressure. Pressure is applied prior to and during the heating process, and heat is created by the electrical resistance occurring at the points of contact between the surfaces. Upset welds are commonly used in the fabrication of wire rings, burner rings, wheel rims, and other circular components with small cross-sectional areas.
The upset welding process delivers several distinct benefits, including:
High-quality welds with fewer fusion defects
Compatibility with a wide variety of standard and difficult-to-weld materials
Welding equipment that is easy to control, operate, and maintain
Welding Services from Chapter 2, Inc.
Choosing the appropriate weld type for a given welding application is critical to the performance, reliability, and safety of the final welded component. At Chapter 2, Inc., we are an ISO 9001:2015-certified full-service manufacturer offering various welding services to meet different welding requirements. Our capabilities include MIG, TIG, aluminum, and robotic welding, allowing us to handle complex welds or difficult-to-weld materials with exceptional efficiency.
Contact us to learn more about the various weld types and how we can customize our manufacturing approach to meet your needs. To get started on your next project, request a quote today using our online form.
